Fire Panel 4 Zone Metal Non Addressable

The FP 4003 non-addressable control and indicating equipment forms the central part of a redetection and alarm system. The 2-wire FP 4003 is compatible with TRONIC non-addressable devices. The FP 4003 comes standard with features that allows flexibility and expandability. Default configuration programming facilitates out-of-box installation and rapid commissioning. The FP 4003 control panel provides re detection and alarm system designers with an economical product for life safety and property protection applications.

Features:

• 2, 4, 8 or 16 detection zones
• Up to 32 non-addressable devices per alarm zone circuit
• Configurable non-latching alarm zones, alarm dependency (zone coincidence detection), and output delay timer
• 3 Access Levels
• Single-person test mode
• Day/night mode
• Manual activation of audio/visual alarm devices
• Supervised auxiliary DC 24 V output
• 2 independently programmable non-addressable A/V alarm output circuits
• 2 programmable Fire Alarm relay outputs
• Fault relay output
• 3 voltage-free inputs for remote reset, evacuation start/stop, and Day/Night mode
• Supports up to 7 Repeater Panels

Warranty:

1 Year
